Pipe-lump Shredder-crusher machine
1.Space-saving and investment-minimized, compared to the individual shredder, granulator and conveyor.
2.One-step size reduction to desired final output size.
3.Slanted pusher ram ensures continuous operation & eliminates residual materials.
4.Auto-reverse system re-orients shredder rotor’s direction when motor overload and material jam.
5.Shredder rotor knife adopts DC53 and crusher knife adopts Cr12MoV.
6.Shredder and crusher are individually driven for better control.
7.Main electrical components are trusted brands such as Siemens and Schneider.
- 1.Plastics rubber lumps
2.Plates
3.Scrap
4.Frames
5.Pipes, PET bottles, etc
| Model |
PTSC600 |
PTSC800 |
PTSC1000 |
| Dimension(L*W*H)mm |
1850*1500*1900 |
2750*2000*2300 |
3380*2500*2700 |
| Shredder operation length(mm) |
1200*1090 |
1400*1500 |
1600*1880 |
| Discharge height(mm) |
600 |
800 |
800 |
| Shredder motor power(kw) |
18.5 |
37 |
45 |
| Shredder rotation diameter(mm) |
220 |
380 |
400 |
| Shredder rotation speed(Rpm) |
80 |
60 |
60 |
| Shredder rotated blades number |
27 |
39 |
49 |
| Shredder fixed blades number |
4 |
4 |
4 |
| Shredder screen hole size(mm) |
40 |
40 |
50 |
| Shredder screen number |
1 |
1 |
1 |
| Hydraulic power(kw) |
2.25 |
3.75 |
3.75 |
| Crusher motor power(kw) |
15 |
22 |
30 |
| Crusher rotation diameter(mm) |
260 |
320 |
410 |
| Crusher rotation speed(Rpm) |
580 |
450 |
450 |
| Crusher rotated blades number |
6 |
6 |
6 |
| Crusher fixed blades number |
1 |
1 |
1 |
| Crusher screen hole size(mm) |
12 |
12 |
12 |
| Crusher creen number |
1 |
1 |
1 |
| Weight(kg) |
2170 |
5250 |
6800 |
